2
To Test SafeSense ® Technology
15
15
15
Breakthrough Safety Technology! SafeSense ® stops shredding when hands are too close to the opening.
Window
See safety instructions below
Bin
Shredder head
Control switch
Auto-On (I)
Off (O)
Reverse (R)
SafeSense ® Override Switch
Active Not active
Press Auto-On (I) Touch test area Sensor lights up
Sheet capacity icon
ENGLISH
Model P-58Cs
15
15
• Keep away from children and pets. Keep hands away from
paper entry. Always unplug when not in use.
• Keep foreign objects – gloves, jewelry, clothing, hair,
etc.– away from shredder openings. If object enters
top opening, switch to Reverse (R) to back out object.
• Never use aerosol, petroleum-based or other flammable products on or
near shredder. Do not use canned air on shredder.
• Do not use if damaged or defective. Do not open shredder head. Do not
place near or over heat or water source.
• 9 sheets per pass to avoid jams.
• Avoid touching exposed blades under Cross-Cut shredder head. • The grounded socket-outlet shall be installed near the equipment and shall be
easily accessible.
Will shred: Paper, credit cards, staples
Will not shred: Continuous forms, adhesive labels, transparencies, newspaper,
cardboard, paper clips, laminates or plastic other than
noted above
Paper shred size:
Cross-Cut ........................................................................ 5/32” x 2” (3.9 x 50mm)
Maximum:
Sheets per pass ...................................................................................................9*
Cards per pass .....................................................................................................1*
Paper width ..................................................................................8 3/4” (225mm)
Continuous operation ............................................................................ 3-5 minutes
*20 lb., 8.5”x11” paper at 120v, 60Hz, 3.5Amps; heavier paper, humidity or
other than rated voltage may reduce capacity. Recommended daily usage rates:
10-20 paper passes; 10 cards.
Fellowes SafeSense ® shredders are designed to be operated in home and office
environments ranging between 50 – 80 degrees Fahrenheit (10 – 26 degrees Celsius)
and 40 – 80% relative humidity.
CAPABILITIES
IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!
Sheet capacity gauge
Paper/credit card entry
SafeSense ® (yellow)
SafeSense ® Technology
Overheated (red)
Standby (green)
LED Lights
Disconnect power switch
Continuous operation:
3-5 minute maximum
NOTE: Shredder runs briefly
after each pass to clear entry.
Continuous operation beyond
3-5 minutes will trigger 15-minute
cool down period.
Paper jam: Set to Off (O), remove shredder head and empty bin. Replace shredder head, and follow any or all of the below procedures.
Run regularly in reverse for
one minute
Oil when bin is full, or
immediately, if:
• Capacity decreases
• Motor sounds different, or
Shredder stops running
PAPER
CARD
Set to Off (O)
and plug in
3
15
15
Indicator lights:
Yellow - SafeSense ® active
Yellow flashing - SafeSense ® not active
Make sure head is on basket correctly
Wait 15 minutes for motor to cool down
Remove and empty basket
ATTENTION: If the SafeSense ® light remains on, you must engage the Override Switch in order to perform steps above. Once the jam is cleared, reset the
SafeSense ® feature. (See SafeSense ® instructions below.)
*Apply oil
across entry
Set to Reverse
(R) 2-3 seconds
Set to Off (O) Set to Auto-On (I)
Feed into paper entry
and release
Set to Auto-On (l) Check paper amount
Feed into center of entry
and release
Hold card at edge Set to Auto-On (l)
Set to Off (O)
and unplug
Gently pull uncut paper
from paper entry. Plug in.
Set to Reverse (R)
for 2-3 seconds
Set to Off (O)
and unplug
Set to
Reverse (R)
Alternate slowly back and forth
Sensor light illuminated–paper jammed
SafeSense ® paper jam: If the SafeSense ® feature activates (SafeSense ® light remains on) to cause the user to think
the shredder has jammed when it has not, use the Override Switch to deactivate the SafeSense ® feature and clear
the paper. Warning – when switch is in override position, the SafeSense ® light will flash and the SafeSense ® feature will
NOT function. Once the paper is cleared, reset the SafeSense ® feature.
LIMITED WARRANTY Fellowes, Inc. (“Fellowes”) warrants the cutting blades of the machine to be free from
defects in material and workmanship for 5 years from the date of purchase by the original consumer.
Fellowes warrants all other parts of the machine to be free of defects in material and workmanship for 1
year from the date of purchase by the original consumer. If any part is found to be defective during the
warranty period, your sole and exclusive remedy will be repair or replacement, at Fellowes’ option and
expense, of the defective part.
This warranty does not apply in cases of abuse, mishandling, or unauthorized repair. ANY IMPLIED
WARRANTY, INCLUDING THAT OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS HEREBY
LIMITED IN DURATION TO THE APPROPRIATE WARRANTY PERIOD SET FORTH ABOVE. In no event shall
Fellowes be liable for any consequential or incidental damages attributable to this product.
This warranty gives you specific legal rights. The duration, terms, and conditions of this warranty are valid
worldwide, except where different limitations, restrictions, or conditions may be required by local law.
For more details or to obtain service under this warranty, please contact us or your dealer.
OPERATION
TROUBLESHOOTING
MAINTENANCE
WARRANTY
Disconnect power switch must be in ON (I) position to operate
shredder. Insert waste bag (Fellowes #36052) for easy disposal.
*Only use a non-aerosol vegetable oil in long nozzle container such as Fellowes 35250
Follow oiling procedure below and repeat twice.
Shred one sheet
SafeSense ® override switch
Active Not active
