Assembly
7
• Fit the end of each swing arm into the grooves in the seat.
Swing Arm
Groove
Side View
Side View
• Fit the side rails under the grooved areas under the seat, as shown.
• Insert four #8 x 2,5 cm screws into the holes in the seat.
• Tighten the screws with the Allen wrench.
Side Rails
6
• Make sure the tab on each side of the seat back is fitted inside
the socket on each side of the seat bottom.
• Insert the hinge rod through the hinge on the seat assembly.
• Insert a #8 x 2,5 cm screw into the end of the hinge rod.
Tighten the screw with the Allen wrench.
Hinge Rod
Side View
Side View
5
Tab
Tab
• Insert a #8 x 2,5 cm screw into each swing arm. Tighten the
screws with the Allen wrench.
IMPORTANT! Push down on the seat assembly to be sure it’s
secure to the swing arms.
Swing Arms
Side View
Side View
