PACKAGE AVAILABILITY
No. of Pins/Balls Pin/Ball Pitch Dimensions
TAB-BGA (Cavity-down)
304 0.8 mm 21 mm
352 0.8 mm 23 mm
480 1.0 mm 31 mm
560 1.0 mm 35 mm
660 1.0 mm 40 mm
720 1.0 mm 40 mm
EBGA (Cavity-down)
576 1.27 mm 40 mm
672 1.27 mm 45 mm
HQFP (Cavity-up)
208 0.50 mm 28 mm
240 0.50 mm 32 mm
256 0.40 mm 28 mm
304 0.50 mm 40 mm
TQFP (Cavity-up)
100 0.50 mm 14 mm
120 0.50 mm 20 mm
LQFP (Cavity-up)
144 0.50 mm 20 mm
176 0.50 mm 24 mm
208 0.50 mm 28 mm
FBGA (Cavity-up)
112 0.80 mm 10 mm
144 0.80 mm 12 mm
168 0.80 mm 12 mm
176 0.80 mm 12 mm
192 0.80 mm 14 mm
224 0.80 mm 16 mm
240 0.50 mm 10 mm
272 0.80 mm 18 mm
288 0.75 mm 18 mm
304 0.50 mm 12 mm
320 0.80 mm 18 mm
368 0.50 mm 14 mm
FC-BGA (Cavity-down)
1,089 1.27 mm 42.4 mm
1,225 1.27 mm 45.0 mm
1,369 1.27 mm 47.5 mm
1,681 1.00 mm 42.5 mm
1,849 1.00 mm 45.0 mm
2,116 1.00 mm 47.5 mm
0.18µm CMOS Technology
Fujitsu Microelectronics, Inc.
