FS-8704-01 SMC TCP/IP Manual Page 10 of 12
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.fieldserver.com
Tel: (408) 262-2299 Fax: (408) 262-9042 Toll_Free: 888-509-1970 email: [email protected]
CONFIGURING THE FIELDSERVER AS A SMC TCP/IP SERVER 5
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See “.csv” sample files provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with a SMC TCP/IP Client.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for SMC TCP/IP communications, the driver independent FieldServer buffers need to be declared in
the “Data Arrays” section, the FieldServer virtual node(s) needs to be declared in the “Server Side Nodes” section,
and the data to be provided to the clients needs to be mapped in the “Server Side Map Descriptors” section.
Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
5.1 Server Side Connection Descriptors
Section Title
Connections
Column Title
Function Legal Values
Adapter Adapter Name N1
Protocol Specify protocol used SMT
Example
// Server Side Connections
Connections
Adapter ,Protocol
N1 ,SMT
