Fairchild CAM/CMOS-2K.LS - Manual (Page 18)

SBS
Value Function
Set bit shift 0 12 bit
1 10 bit
2 8 bit
CAO
Adjust analog video offset mismatch. Calibrate analog offset 200 DN.
SAG
Set analog gain 0 – 10 db
CAG
Adjust analog video gain mismatch. Calibrate analog gain.
GSN
Get camera serial number, returns 128 character string: serial number, model, etc.
SGH
Set gain high. Set pixel gain in sensor.
SGL
Set gain low. Set pixel gain in sensor.
3.3 Camera Command Summary
Table 3.3.1
Command Definition Summary
RSH Reboot System Hard Hard reboot of camera
RSS Reset Command Logic reset of camera
INQ Inquiry Shows what camera is used
VER Version Shows current software
SLR Set Line Rate This function allows line rate change
CPO Calibrate Pixel Offset This function performs correction of pixel
offset
CPG Calibrate Pixel gain This function performs correction of pixel
gain
VOM Voltage monitoring This function shows internal voltages
TSB Temperature Sensor Board This function shows temp. of sensor board
SIT Set Integration Time This function allows user to set integration
time
SSM Set Sync Mode This function allows user to select sync
mode
SCM Select Correction Mode This function allows user to select
correction mode
STP Select Test Pattern This function allows user to select test
pattern
Fairchild Imaging • CAM/CMOS-2K.LS Line Scan Camera User’s Manual • Rev C• 18 of 42
