Huffy 214953C - Manual (Page 22)

22
P/N 214953C 12/03
53
49
52
Roll completed assembly to desired position. Secure assembly to ground using anchor
strap (52) and tie down stake (53). Fill tank with water (approx. 30 gallons/115 Liters)
or sand (approx. 255 lbs./113 kg) and snap cap (49) in place.
DO NOT LEAVE
ASSEMBLY UNATTENDED
WHEN EMPTY; IT MAY TIP
OVER.
WARNING!
ADD TWO GALLONS (7.6
LITERS) OF NON-TOXIC
ANTIFREEZE IN SUB-
FREEZING CLIMATES.
CAUTION!
41
39
47
43
43
24.
25.
USE EYE PROTECTION
WHEN INSTALLING
SPRINGS.
WARNING!
Insert bolt (47) through left side upper elevator tube (43), then stretch spring (41) onto
bolt (47). Insert bolt (47) through right side upper elevator tube (43) and secure with
nut (39).
