78
ASSEMBLY
Loose Parts
Unpacking
ASSEMBLY
Check all loose parts against the following list. Contact your dealer if
any of the loose parts shown below are not included with your
generator.
Compare the loose parts with the inventory list below.
Remove the generator and loose parts box from the carton.
Tools Required:
1.
2.
14 mm wrench (2), pliers (not included)
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Description
Wheel
Axle
Handle assy
Rear pipe
Stand
20 mm Washer
4.0
28 mm Cotter pin
12 mm Washer
Spring Washer
Handle holder bolt
8
45 mm Flange bolt
8 16 mm Flange bolt
8 16 mm Flange bolt (black)
Hanger
Hanger bracket
Qty.
2
1
1
1
2
2
2
2
2
2
2
8
4
1
2
