Hayter Mowers RS82 - Manual (Page 19)

111-0550TH231105A
REAR AXLE AND CONTROL PEDALS 1.19 1.19
ITEM NO. DESCRIPTION. PART NO. QTY. ITEM NOTE.
51 Washer AL704538 1
52 Spacer AL51866030 1
53 Bolt AL701704 6
54 Bolt AL704546 2
55 Tyre AL461534 2
56 Bearing Assembly AL514081 1
57 Pulley AL514075 1
58 Spring LH AL514295 1
59 Pedal Arm Left AL52118530 1
60 Pedal Left AL51416801 1
61 Pedal Stop AL521188 1
62 Screw AL582737 2
63 Lock Fix AL52118630 1
64 Lock Pivot AL52118730 1
65 Clutch Cable AL514070 1
66 Key AL522531 1
67 Nut AL704537 7
68 Nut AL-------- 4
69 Throttle Control AL514382 1
70 Remote Control Lever AL514395 1
71 Screw AL700961 1
72 Nut AL701352 1
73 Screw Left AL702830 2
74 Nut AL700119 2
75 Nut AL521375 2
76 Washer AL700200 2
77 Nut AL704536 2
78 Washer AL703005 1
79 Screw Hexagon AL704368 2
80 Cap AL461289 2
