English
11
Fig. 7 Fig. 8
Fig. 5 Fig. 6
4. Move the side handle
The side handle can be fixed at any
desired position; 360 degrees, and can
also be fixed at any position in the back-
and-forth direction.
(1) Loosen the handle by turning the grip in
the direction of A as shown in Fig. 5.
(2) Adjust it to a position where vertical (up-
and-down) operation can be facilitated as
illustrated in Fig. 6, Fig. 7, and Fig. 8.
(3) Turn the grip in the direction of B and fix
the handle.
Grip
A B
