HomeTech Rackmount Light LT1R User Manual
Lt-1r rackmount light, Engineered mounting solutions, Features architects’ and engineers’ specifications
Rackmount light shall be Middle Atlantic Products model # LT-1RX (X = finish,
refer to chart). One rackspace rackmount light shall contain retractable light shelf
with LED light bar containing a total of ten white and amber lights for color
balance. Rackmount light shall include front mounted dimmer knob (LT-1R only).
Hidden dimmer switches to control logo and light brightness on bottom of
retractable light shelf (LT-1RA and LT-1RC). Light shelf shall extend and light bar
shall illuminate automatically when pressed. Rackmount light shall have ball
bearing slides for retractable light shelf and shall have a weight capacity of 20 lbs.
Rackmount light shall be constructed of 18-gauge steel. Unit shall provide two
rear USB style, 5 volt DC output ports for use with optional gooseneck LED
light. Rackmount light shall be warrantied to be free from defects in material or
workmanship under normal use and conditions for a period of 3 years.
• Retractable LED light shelf
• Dimmable LED light bar provides evenly
distributed illumination for componant viewing
• Constructed of 18-gauge steel
• Available in durable flat black powdercoat,
black brushed and anodized or silver brushed
and anodized finish
• 2 rear USB style output ports for connection of LED
gooseneck work lights
• Aesthetically pleasing dimmable LED logo optional
(LT-1RA, LT-1RC)
• UL Listed plug-in power supply
Rackmount light provides ambient lighting to front and rear of
rackmount components
LT-1R Rackmount Light
96-01050 / rev 1 / 12-19-05
96-01050 / rev1 / 12-19-05 / L
T-1R
Features
Architects’ and Engineers’ Specifications
Engineered Mounting Solutions
US: Riverdale, NJ • Simi Valley, CA • Harvey, IL • Voice: 973-839-1011 Fax: 973-839-1976 • middleatlantic.com
Canada: Ottawa, ON • Port Coquitlam, BC • Voice: 613-836-2501 Fax: 613-836-2690 • middleatlantic.ca
e l e c t r o n i c v e r s i o n a v a i l a b l e a t m i d d l e a t l a n t i c . c o m
EIA
Compliant
m i d d l e a t l a n t i c . c o m
Middle Atlantic Products, Inc.
I-00171
(LT-1R) Front View
Rear View
OPTIONS
• Gooseneck light shall be Middle Atlantic Products model # LT-GN
LT-GN
(LT-1RA) Front View
(LT-1RC) Front View
