Hearth & Home Technologies • Bravo, Aztec • InD • 703-900 Rev. N • 8/06 14
2. Top Vent - Vertical Termination
No Elbow
Figure 5.6
V
1
= 46 ft. Max. (14.0 m)
Note: A 45 O elbow may be attached
directly to starting collars on unit only
if used in conjunction with a return 45
O
elbow AND terminating vertical with V =
8 feet MINIMUM.
A straight section of pipe can be used
between the two 45
0 elbows.
8 FT.
(2.4mm)
FLUE
OUTLET
