Hyundai EXCELLENCE H-CMD2002 User Manual
Page 24
24
Aspect ratio
The aspect ratio alters according to the following while pressing the WIDE button on the front panel or the remote
control – FULL -> WIDE -> NORMAL -> OFF.
FULL - The screen is extended horizontally as a whole to the aspect ratio of 16 to 9.
The extension ratio is the same at any point of the screen.
WIDE - The screen is extended horizontally to the aspect ratio of 16 to 9.
The extension ratio increases toward the right and left end of the screen.
NORMAL - The conventional display image has a 4 to 3 ratio of horizontal to vertical.
In this case, a blank area remains on the right and left sides of the display.
Image setting
The video output format for the each playing source is listed as below:
Playing source Video output format
TUNER
RGB mode
DVD
RGB mode
AUX IN
CVBS mode
CAMERA
CVBS mode
NAVI
RGB mode
1. Press the PIC button on the RC or press and hold for 2 seconds the WIDE/PIC button on the monitor to
open the image adjustment menu.
