24
2. Connect the hot and cold water inlet hoses to the hot and cold water faucets
respectively.
3. Connect the other end to their respective washer inlet located at the rear.
Note: Hot water needs to be at a temperature of at least 120˚F – 140˚F.
(49˚C- 60˚C) for the soap to dissolve and to avoid soap residue
remaining on clothes.
4. Install the drain hose into a drain pipe. The drain hose must be placed into a
drainpipe at least 1 1/2 inches in diameter or directly into a sink. Use the “goose
neck” to hold hose in place. To avoid possible water back up, the drain hose
must reach height of at least 31
1/2 inches minimum and 40 inches maximum. If
the sink is less than 37 1/2 inches in height, route drain
hose through the clip on the back of the machine.
English
Drain Hose
Water Supply Hose
Hose Bend Drain Hose
Goose Neck Water Inlet
11
SINK
