9
Using Your Hob
Hob Units - Features
Model No. BE32 240V
Heating Areas:
(1) 1.2kW
(2) 1.8kW
(3) 1.2kW
(4) 1.8kW
230 - 240V ˜ 5.5 - 6.0 kW
50Hz
1
2
3
4
The hob has four cooking areas which are indicated on the hob glass. There is also an on/off light
which comes on when one or more of the cooking areas are switched on.
The knobs can be rotated in either direction to provide fully variable heat control.
All models also have a hot hob warning light, to indicate when any heating area may be
hot. This illuminates when any control is switched on and remains illuminated for some time after
switching the control off.
2 1
4 3
The rating plate for all models is situated on the underside of the base panel.
❍
❍
❍
❍
