MHC36 AND MHR36 INSTALLATION INSTRUCTIONS
C. SYSTEM COMPONENTS
1. Fireplace Components
Bi-Fold Glass Doors
DM1036
DM1036B
DM1036S
Perception Glass Doors
DP1036
DP1036B
DP1036S
*The junction box and fan kit should be installed at the time of initial fireplace installation.
Otherwise, significant reconstruction will be required. Refer to the installation instructions included
with the JK9 and FK22 for proper installation.
BC10 - Fan Motor
Rheostat Control
(MHC36 only)
FK22 - Fan Kit (MHC36 only)
HX3 - Hearth Extension
GR16 - Integral Grate
Catalog # Description:
MHR36 Radiant Fireplace, with Integral Grate, Hearth Protection Strips and Outside Air Kit
MHC36 Circulating Fireplace, with Integral Grate, Hearth Protection Strips, Fan Kit and Junction Box
DM1036 Bi-fold Glass Doors - Black Finish
DM1036B Bi-fold Glass Doors - Polished Brass Finish (included with fireplace)
DM1036S Bi-fold Glass Doors - Stainless Steel Finish
DP1036 Peception Glass Doors - Black Finish
DP1036B Perception Glass Doors - Polished Brass Finish
DP1036S Perception Glass Doors - Stainless Steel Finish
FK22* Fan Kit (MHC36 only)
JK9* Junction Box (MHC36 only)
BC10 Fan Motor Rheostat Control (MHC36 only)
HX3 Hearth Extension
GR16 Integral Grate (included with fireplace)
Outside Air Kit (included with fireplace)
