18
Specification
Specifications are subject to change without notice.
Mass and dimension are approximate.
General. Power supply 12V DC (11V-16V) Test voltage 14.4V, negative ground
Maximum power output: 50Wx4 channels
Rated power output (RMS): 25Wx4 channels (4 10% T.H.D.)
Suitable speaker impedance: 4-8 ohm
Pre-Amp output voltage: 2.0V(CD play mode: 1KHz, 0 dB, 10K load)
Fuse: 15A
Dimensions (W x H x D) / Weight: 178 50 166 mm / 1.7kg
ESP CD (40s), MP3 (120s)
FM Stereo Radio. Frequency range: 87.5 - 108.0 MHz
Usable sensitivity / Signal/noise ratio 12 dB / 55dB
Frequency response: 30 Hz-15kHz
Stereo separation: 25dB (1kHz )
Image response ratio / IF response ratio: 50dB / 70dB
AM Radio. Frequency range: 522-1620 KHz
Usable sensitivity(S/N=20dB): 30 dB
Disc Player. System: Disc digital audio system
Frequency response: 20 Hz - 20 kHz
Signal/noise ratio: >86 dB
Total harmonic distortion / Wow and flutter: Less than 0.5%(1 kHz) / Below measurable limits
Channel separation: >60 dB
