Hanns.G HW173DB User Manual
Hw173db
HW173DB
3
LCD Panel
Display size
17" (43,18 cm) WIDE
4
Panel Type
Active Matrix TFT
5
Brightness
250 cd/m² (typ.)
6
Contrast ratio
500:1 (typ.)
7
Pixel pitch
0.255(H)*0.255(V) mm
8
Resolution (H x V)
WXGA+ 1440 x 900
9
Response time
8 ms (typ.)
10
View angles LR,UD
H/V 140°/130°
11
Display colors
16.2M Colors
12
Color
9300K, 6500K, User Mode
13
Display Surface
Anti-Glare
15
Input
Input 1
D-Sub
16
Input 2
DVI-D
17
Input 3
19
Output
Output 1
20
Output 2
21
Headphone
22
Speakers
24
Power
Supply
AC 100~240V, 50~60Hz
25
Consumption
28 W
27
Operating Condition
Temperature
5 ~ 35°C
28
Humidity
10 ~ 85%
30
Physical
Dimension (W*D*H)
405 x 199 x 380 mm
31
Packing dimension (W*D*H)
450 x 137 x 417 mm
32
Net weight
3,4 kg
33
Gross weight
5 kg
34
Tilt
0°~ 20°
35
Kensington Lock
ü
36
VESA mounting
VESA Standard, 100mm
38
Controls
Front control
Auto, Vol(-), Power/LED,
Vol(+), Menu
39
On screen display
EN,TC,DE,FR,ES,IT,PT,NL
,SC,JS,KR
41
Certification
Safety
UL/CUL, TUV, CB, BSMI,
FCC, CE, GOST
42
Emission
MPR II
43
Power saving
EPA Energy Star
44
Extras 1
45
Extras 2
46
Extras 3
47
Accessories
powercord, VGA cable,
users manual (CD),
quickstart guide (paper),
warranty card
ENG
48
Specifications are subject to change without notice. Error accepted.
