3

Enclosure Mounting Diagrams (continued)

3.35"

(85mm)

12"

(304.8mm)

14.25"

(362mm)

5.88"

(149.2mm)

5.88"

(149.2mm)

3.92"

(99.6mm)

2.5"

(63.5mm)

1.5"

(38.1mm)

1.5"

(38.1mm)

1.5"

(38.1mm)

1.5"

(38.1mm)

1.5"

(38.1mm)

1.5"

(38.1mm)

DETAIL B

1.13"

(28.6mm)

0.88"

(22.2mm)

0.6"

(15.1mm)

1.15"

(29.3mm)

5.25"

(133.4mm)

1.25"

(31.8mm)

B
