TECHNICAL DATA
Model Name
Leica Cine 1 - 80
Leica Cine 1 - 100
Leica Cine 1 - 120
Active picture diagonal
80”
100”
120”
Image resolution
3840 x 2160 pixels
3840 x 2160 pixels
3840 x 2160 pixels
Audio output strength
2 x 25 W
2 x 25 W
2 x 25 W
Power supply
120–240 V – 50/60 Hz
120–240 V – 50/60 Hz
120–240 V – 50/60 Hz
Energy consumption
Normal operation
Power usage in network standby
mode (Wake on LAN)
Energy consumption in standby mode
max 185 W
2.0 W
0.5 W
max. 320 W
2.0 W
0.5 W
max. 320 W
2.0 W
0.5 W
HDMI port
RGB / 60 Hz (640 x 480, 800 x 600,
1024 x 768) YUV / 60 Hz (480i, 480p, 720p,
1080i, 1080p) YUV / 50 Hz (576i, 720p,
1080i, 1080p)
3840 x 2160 / 24 Hz, 3840 x 2160 / 25 Hz,
3840 x 2160 / 30 Hz, 3840 x 2160 I 50 Hz,
3840 x 2160 I 60 Hz
RGB / 60 Hz (640 x 480, 800 x 600,
1024 x 768) YUV / 60 Hz (480i, 480p, 720p,
1080i, 1080p) YUV / 50 Hz (576i, 720p,
1080i, 1080p)
3840 x 2160 / 24 Hz, 3840 x 2160 / 25 Hz,
3840 x 2160 / 30 Hz, 3840 x 2160 I 50 Hz,
3840 x 2160 I 60 Hz
RGB / 60 Hz (640 x 480, 800 x 600,
1024 x 768) YUV / 60 Hz (480i, 480p, 720p,
1080i, 1080p) YUV / 50 Hz (576i, 720p,
1080i, 1080p)
3840 x 2160 / 24 Hz, 3840 x 2160 / 25 Hz,
3840 x 2160 / 30 Hz, 3840 x 2160 I 50 Hz,
3840 x 2160 I 60 Hz
Receiver system
Analog
Digital
PAL-D/K, B/G, I, SECAM-D/K, B/G
DVB-T/T2, DVB-C, DVB-S/S2
PAL-D/K, B/G, I, SECAM-D/K, B/G
DVB-T/T2, DVB-C, DVB-S/S2
PAL-D/K, B/G, I, SECAM-D/K, B/G
DVB-T/T2, DVB-C, DVB-S/S2
Wi-Fi
IEEE802.11 a/b/g/n/ac
IEEE802.11 a/b/g/n/ac
IEEE802.11 a/b/g/n/ac
WLAN module
Model
Frequency range
Output (max.)
TX7921AU64T
2.4-2.4835 GHz
5.15-5.85 GHz
5.9-6.425 GHz
2.4-2.4835 GHz, 17 dBm
5.15-5.25 GHz, 14d Bm
5.25-5.35 GHz (DFS Band), 14 dBm
5.49-5.71 GHz (DFS/TPC Band), 14 dBm
5.725-5.85 GHz (for non-EU countries),
14 dBm
5.9-6.425 GHz, 14 dBm
TX7921AU64T
2.4-2.4835 GHz
5.15-5.85 GHz
5.9-6.425 GHz
2.4-2.4835 GHz, 17 dBm
5.15-5.25 GHz, 14d Bm
5.25-5.35 GHz (DFS Band), 14 dBm
5.49-5.71 GHz (DFS/TPC Band), 14 dBm
5.725-5.85 GHz (for non-EU countries),
14 dBm
5.9-6.425 GHz, 14 dBm
TX7921AU64T
2.4-2.4835 GHz
5.15-5.85 GHz
5.9-6.425 GHz
2.4-2.4835 GHz, 17 dBm
5.15-5.25 GHz, 14d Bm
5.25-5.35 GHz (DFS Band), 14 dBm
5.49-5.71 GHz (DFS/TPC Band), 14 dBm
5.725-5.85 GHz (for non-EU countries),
14 dBm
5.9-6.425 GHz, 14 dBm
Bluetooth
BT 5.2
BT 5.2
BT 5.2
Bluetooth module
Model
Frequency range
Output (max.)
TX7921AU64T
2.4-2.4835 GHz
2.4-2.4835 GHz, Class1, 6 dBm
TX7921AU64T
2.4-2.4835 GHz
2.4-2.4835 GHz, Class1, 6 dBm
TX7921AU64T
2.4-2.4835 GHz
2.4-2.4835 GHz, Class1, 6 dBm
Remote control
Model
Frequency range
Output (max.)
ERF6A64/ERF6B64H
2.4–2.4835 GHz
2.4–2.4835 GHz, 5 dBm
ERF6A64/ERF6B64H
2.4–2.4835 GHz
2.4–2.4835 GHz, 5 dBm
ERF6A64/ERF6B64H
2.4–2.4835 GHz
2.4–2.4835 GHz, 5 dBm
Operating conditions
Temperature: 5°C–40°C
Humidity: 20%–80% RH
Atmospheric pressure: 86 kPa–106 kPa
Temperature: 5°C–40°C
Humidity: 20%–80% RH
Atmospheric pressure: 86 kPa–106 kPa
Temperature: 5°C–40°C
Humidity: 20%–80% RH
Atmospheric pressure: 86 kPa–106 kPa
Weight
14.6 kg
14.6 kg
14.6 kg
Dimensions (W x H x D)
600 x 149.1 x 378 mm
600 x 149.1 x 378 mm
600 x 149.1 x 378 mm
Subject to changes in design and model features.
LEICA CUSTOMER CARE
Please contact the Customer Care department of Leica Camera AG for the
maintenance of your Leica equipment and for help and advice regarding Leica
products and how to order them. You can also contact the Customer Care
department or the repair service provided by your regional Leica subsidiary for
repairs or warranty claims.
LEICA GERMANY
Leica Camera AG
Leica Customer Care
Am Leitz-Park 5
35578 Wetzlar
Germany
Phone:
+49(0)6441 2080-189
Fax:
+49(0)6441 2080-339
Email:
https://leica-camera.com
YOUR NATIONAL REPRESENTATIVE
You will find the Customer Care department responsible for your locality on
our homepage:
https://leica-camera.com/en-US/contact
