6

ENGLISH

Optional Extras

Optional extras can be changed or modified for

quality improvement without any notification.

Contact your dealer for buying these items.
These devices work only with certain models.
The model name or design may be changed due to

the manufacturer’s circumstances or policies.
(Depending upon model)

Magic Remote Control

AN-MR18HA

Check whether your TV model supports Bluetooth in

the Wireless Module Specification to verify whether it

can be used with the Magic Remote.

Wall Mounting Bracket

Make sure to use screws and wall mounts that meet

the VESA standard. Standard dimensions for the wall

mount kits are described in the following table.

A

B

Model

43UT570H0UA
43UT670H0UA
49UT770H0UA
50UT570H0UA
43UT570H9UA
50UT570H9UA
43UT560H9UA
50UT560H9UA

49UT570H0UA
55UT570H0UA
49UT670H0UA
55UT670H0UA
55UT770H0UA
55UT570H9UA
55UT560H9UA

VESA (A x B)

200 x 200

300 x 300

Standard screw

M6

M6

Number of screws

4

4

Wall mount bracket

(optional)

LSW240B
MSW240

OLW480B
MSW240

Model

65UT570H0UB
65UT770H0UB
65UT570H9UB
65UT560H9UB

75UT770H0UA

VESA (A x B)

300 x 300

600 x 400

Standard screw

M6

M8

Number of screws

4

4

Wall mount bracket

(optional)

OLW480B

LSW640B

Lifting and Moving the TV

When moving or lifting the TV, read the following to

prevent the TV from being scratched or damaged and

for safe transportation regardless of its type and size.

It is recommended to move the TV in the box or

packing material that the TV originally came in.

Before moving or lifting the TV, disconnect the

power cord and all cables.

When holding the TV, the screen should face away

from you to avoid damage.

Hold the top and bottom of the TV frame firmly.

Make sure not to hold the transparent part, speaker,

or speaker grille area.

Use at least two people to move a large TV.
