6
The AU-EVA1 is a cinema camera recorder, featuring a newly developed super 35mm sized
imager with 5.7K resolution, and can record in several formats and compression, offering up to
10-bit 4:2:2 even in 4K. The EVA1 contains V-Log/V-Gamut capture to deliver high dynamic range
and a broad color gamut.
1-1. Super 35mm sized imager with 5.7K resolution
The new 17:9 imager (5720 x 3016 active pixels) achieves 2000 horizontal TV lines.
1-2. Active area
The EVA1 uses two different areas on its imager for capturing, depending on frame rate in variable
frame rate (VFR) record mode. The areas, called S35 and 4/3 areas can be changed with the
SENSOR MODE menu item.
MENU > SYSTEM SETTINGS > SENSOR MODE
S35 area (used for up to 120fps per second)
4/3 area (used for up to 240fps per second)
5720 x 3016
Active pixels
1
0.
25
1m
m
19.436mm
1. Sensor & format
24.596mm
1
2.
96
9m
m
