ALEXA 35 Accessories 108
24.2.2 Top Accessories
Low Mode Support LMS-4 K2.0034178
The Low Mode Support LMS-4 is a fully featured top plate for the ALEXA 35. A new
quick release mechanism allows the CCH-5 top handle to be easily removed, without
tools, while retaining superior rigidity while mounted. Dual rod clamps for optically cen-
tered 15 mm rods allow for top mounted motors or traditional viewfinder mounting brack-
ets. Multiple mounting points support a range of accessories and low mode mounting for
the ARRI Artemis and other mechanical stabilizers. For even more mounting options, the
LMS-4 can be extended with the TEB-1.
Universal Adapter Plate UAP-3 K2.0034179
The Universal Adapter Plate UAP-3 is a small and flat staging platform for the ALEXA
35 top accessories, including the Lightweight Camera Handle LCH-1 and Center Cam-
era Handle CCH-2. For more mounting options, the UAP-3 can be extended to the back
with the TEB-1. The UAP-3 can also be attached to the base of the camera when an ul-
tra slim mounting plate is required for small rigging scenarios.
Top Extension Bracket TEB-1 K2.0024062
The Top Extension Bracket TEB-1 extends the Low Mode Support LMS-4 or Univer-
sal Adapter Plate UAP-3, so more accessories, including the Rear Accessory Bracket
RAB-2 and Articulated Mounting Plate AMP-1, can be mounted to the camera's top and
back.
Lightweight Support LWS-6 K2.0023948
The LWS-6 holds two 15 mm lightweight support rods. It is designed as an option to add
lightweight rods to the Lightweight Camera Handle LCH-1 or to the Universal Adapter
Plate UAP-3. When attached, rods are optically centered based on the lightweight rod
standard and allow mounting further accessories like the Mini Viewfinder Bracket MVB-1,
lens motors or matte boxes.
Center Camera Handle CCH-5 K2.0023519
The Center Camera Handle CCH-5 is a full size production top handle that can be quick-
ly attached and removed from the LMS-4 without tools. Featuring a wider, more com-
fortable grip than previous top handles the CCH-5 has been designed to allow common
gimbal top plates to remain mounted to the camera, under the handle. Multiple mounting
points adorn the handle for accessories and existing HEB and HEX handle extensions
can be mounted to the front and rear.
Lightweight Camera Handle LCH-1 K2.0024066
The Lightweight Camera Handle LCH-1 is a lightweight carbon fibre top handle for car-
rying the ALEXA 35 and for mounting accessories. It can be quickly attached to or re-
moved from the camera's top or the Universal Adapter Plate UAP-3 without tools, and
the handle post can be slid forward and backwards in order to balance the camera in
your hand.
Balance Harness Adapter BHA-1 K2.0034554
The Balance Harness Adapter BHA-1 allows the secure attachment and rapid balancing
of the ALEXA 35 when using various camera suspension harnesses. The BHA-1 slips
over the handle of the Lightweight Camera Handle LCH-1 and can be slid forwards and
backwards with a simple thumbscrew. It features a 3/8-16 threaded hole for connection
and can also be used to mount accessories to the top handle.
