RPM
Roof Parapet Mount
•
Aluminum Alloy with Surface Spray Treatment
•
Designed to Be Installed on the Edge of a
Wall
The mount should be installed on a flat
surface. Waterproof rubber is necessary
for outdoor application. The wall must be
capable of supporting at least three times
as much as the total weight of the camera
and the mount.
The mount’s maximum
load capacity is 22 lbs (10 kg).
Available models:
RPM
Specifications
Dimensions
RPM
Camera
Appearance Hikvision White
Material Aluminum Alloy and Steel
Dimension 7.09" x 31.50" x 37.40" (180 mm x 800 mm x 950 mm)
Weight 6.39 lbs (2.90 kg)
