West Penn Plenum-Rated 60700B 14 AWG 4-Conductor Unshielded Fire Alarm Signaling Cable (1000', Red) - Manual

CONSTRUCTION & DIMENSIONS -
CONDUCTOR PARAMETER -
• Number of Conductors 4
• AWG Size 14
• Conductor Stranding Solid
• Conductor Type Bare Copper
• Nominal DCR 2.6 O hm/1000ft
INSULATION PARAMETER -
• Insulation Type Plenum PVC
• Insulation Thi kness 0.09 in
• Insulation Color Code 1.Black,2.Red,3.Brown,4.Blue
SHIELDING PARAMETER -
• Shield Type None
ELECTRICAL CHARACTERISTICS -
• Nom. Cap. Between Conductors 34 pF/ft
OVERALL CONSTRUCTION PARAMETERS -
Jacket Type Flexible Plenum
Jacket Thi kness 0.015 in
Nominal Cable O.D. 0.236 in
Plenum Yes
NEC UL Rating FPLP
RoHS Compliant Yes
Pull Tension 198 lbs
Bend Radius 2.12 in
Cable Weight 72 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS -
UL Flammability NFPA 262 Plenum
Operating Range -0 to 60 Deg C
UL Voltage Rating 300
Construction & Dimensions
Overall Construction
Overall Electrical & Optical Characteristics
Detailed Specification & Technical Data
60700B
Fire Alarm Signaling
14/4 Solid Unshielded FPLP
