Toll Free: 800-245-4964 | www.westpennwire.com
Detailed Specification & Technical Data
254346A
Electrical Performance
Frequency
(Mhz)
Max.
Insertion
Loss
Min.
NEXT
Min.
PSNEXT
Min.
PSACR
Min.
ACR
Min.
PSACRF
(PSELF-
EXT)
Min.
ACRF
(ELF-
EXT)
Min.
PSAACRF
Min. RL
(Return
Loss)
Min.
TCL
Min.
ELTCTL
Max/Min
Input
Imp.
Unfit
Max/Min
Fitted
Imp.
1 MHz 2.1 db/100m 75.3 dB 73.3 dB 71.2 dB 65 dB 68.8 dB 68 dB 67 dB 20 dB 40 dB 35 dB 100 ± 15 Ohm 100 ± 15 Ohm
4 MHz 3.8 db/100m 66.3 dB 64.3 dB 60.5 dB 53 dB 56.8 dB 56 dB 67 dB 23 dB 40 dB 23 dB 100 ± 15 Ohm 100 ± 15 Ohm
8 MHz 5.3 db/100m 60.8 dB 59.6 dB 54.4 dB 46.7 dB 50.7 dB 49.7 dB 61.1 dB 24.5 dB 40 dB 17 dB 100 ± 15 Ohm 100 ± 15 Ohm
10 MHz 5.9 db/100m 60.3 dB 58.3 dB 52.4 dB 45 dB 48.8 dB 48 dB 59.2 dB 25 dB 40 dB 15 dB 100 ± 15 Ohm 100 ± 15 Ohm
16 MHz 7.5 db/100m 57.2 dB 55.2 dB 47.8 dB 41 dB 44.7 dB 43.9 dB 55.1 dB 25 dB 40 dB 10.9 dB 100 ± 15 Ohm 100 ± 15 Ohm
20 MHz 8.4 db/100m 54.8 dB 53.8 dB 45.4 dB 38.8 dB 42.8 dB 41.8 dB 53.2 dB 25 dB 38 dB 9 dB 100 ± 15 Ohm 100 ± 15 Ohm
25 MHz 9.4 db/100m 53.3 dB 52.3 dB 43 dB 36.8 dB 40.8 dB 39.8 dB 51.2 dB 24.3 dB 38 dB 7.1 dB 100 ± 15 Ohm 100 ± 15 Ohm
31.25 MHz 10.5 db/100m 52.9 dB 50.9 dB 40.4 dB 35.1 dB 38.9 dB 38.1 dB 49.3 dB 23.6 dB 35.1 dB 5.1 dB 100 ± 15 Ohm 100 ± 15 Ohm
62.5 MHz 15 db/100m 48.4 dB 46.4 dB 31.4 dB 29.1 dB 32.9 dB 32.1 dB 43.3 dB 21.5 dB 32 dB 100 ± 15 Ohm 100 ± 15 Ohm
100 MHz 19.1 db/100m 45.3 dB 43.3 dB 24.2 dB 25 dB 28.8 dB 28 dB 39.2 dB 20.1 dB 30 dB 100 ± 15 Ohm 100 ± 15 Ohm
155 MHz 24.1 db/100m 41.4 dB 39.4 dB 18.9 dB 22.1 dB 27.1 dB 25.6 dB 37.1 dB 19.2 dB 29 dB 100 ± 15 Ohm 100 ± 15 Ohm
200 MHz 27.6 db/100m 40.8 dB 38.8 dB 11.2 dB 19 dB 22.8 dB 22 dB 33.2 dB 18 dB 27 dB 100 ± 15 Ohm 100 ± 15 Ohm
250 MHz 31.1 db/100m 39.3 dB 37.3 dB 6.3 dB 17 dB 20.8 dB 20 dB 31.2 dB 17.3 dB 26 dB 100 ± 15 Ohm 100 ± 15 Ohm
300 MHz 34.3 db/100m 38.1 dB 36.1 dB 1.9 dB 15.5 dB 19.3 dB 18.5 dB 29.7 dB 16.8 dB 25.2 dB 100 ± 15 Ohm 100 ± 15 Ohm
350 MHz 37.2 db/100m 36.1 dB 35.1 dB 13.9 dB 17.9 dB 16.9 dB 28.3 dB 16.3 dB 24.6 dB 100 ± 15 Ohm 100 ± 15 Ohm
400 MHz 40.1 db/100m 35.3 dB 34.3 dB 12.8 dB 16.8 dB 15.8 dB 27.2 dB 15.9 dB 24 dB 100 ± 15 Ohm 100 ± 15 Ohm
450 MHz 43.3 db/100m 34.8 dB 35.5 dB 12.1 dB 15.7 dB 14.8 dB 26.1 dB 15.5 dB 23.5 dB 100 ± 15 Ohm 100 ± 15 Ohm
500 MHz 45.3 db/100m 34.8 dB 32.8 dB 11 dB 14.8 dB 14 dB 25.2 dB 15.2 dB 23 dB 100 ± 15 Ohm 100 ± 15 Ohm
550 MHz 48.2 db/100m 34.1 dB 32.2 dB 10.5 dB 14 dB 13.2 dB 24.45 dB 14.9 dB 100 ± 15 Ohm 100 ± 15 Ohm
RELATED PRODUCTS -
Non Plenum Item 4346A
Jack KJ458MT-C6AC-xx
Modular Plug CN-CAPFMUL-S1
Modular Plug 2 32-EZEx48 - Use Tool: TL-EXOCRIMP
POE 10BaseT 100BaseT 1000BaseT 2.5G/5GBaseT 10GBaseT
15W PoE (Type 1) 140m (459 ft) 140m (459 ft) 100m (328 ft) 100m (328 ft) 100m (328 ft)
30W PoE (Type 2) 130m (426 ft) 130m (426 ft) 100m (328 ft) 100m (328 ft) 100m (328 ft)
60W PoE (Type 3) 130m (426 ft) 130m (426 ft) 100m (328 ft) 100m (328 ft) 100m (328 ft)
100W PoE (Type 4) 120m (394 ft) 120m (394 ft) 100m (328 ft) 100m (328 ft) 100m (328 ft)
Channel Reach -PoE
