EN
Package contents
Caps for lens and eyepiece – included in package
Binocular strap – included in package
Optical cloth – included in package
Transport package with strap – included in
package
Caps for lens and eyepiece – included in package
04
Adjusting the dioptric correction
Dioptric correction adjustment procedure:
– Cover the right objective with the cap
– Focus using knob #4
– Uncover the right objective and cover the left objective with
the cap
– Focus using knob #5 (make sure not to turn knob #4 in the
process)
03
Adjusting the slide-out eye guards
(leave eyepieces in retracted position if using eyeglasses)
02
Inter-eye setting
(interpupil) distance
Image focusing
01
Important!
01
Protect the binocular from falling
and hard impact
02 Only clean the glass as recommended
03 Protect the optical surfaces with caps
04
Leave eyepieces in retracted position
if using eyeglasses
