Slave and Preflash Settings
The Impact Digital Monolight has seven optical
slave/preflash modes.
Press the slave button to activate slave mode. The
slave indicator light appear on the display. Press it
again to turn it off.
To adjust the preflash settings, press and hold the slave button for four seconds.
Use the and buttons to toggle between preflash settings.
C0: Using your master flash, release
a test exposure. The monolight
will automatically memorize the
amount of preflashes fired.
C1: The monolight will flash when it
detects another flash.
C2: The monolight will trigger after
one preflash.
C3: The monolight will trigger after
two preflashes.
C4: The monolight will trigger after
three preflashes.
C5: The monolight will trigger after
four preflashes.
C6: The monolight will trigger after five
preflashes.
Once the preflash is set, press and hold the Slave button for 4 seconds to return
to the main screen.
