45
Display example for the [BC-DWX Viewer]
tab
The following is displayed when the battery charge is
100%.
The display is highlighted as follows when a battery
charger is selected in the [Device List] or [BC-DWX
Viewer].
The following is displayed when an error or warning
occurs.
Error: Overvoltage or charging error detected
Warning: Abnormal temperature (high or low) detected
“No Battery” is displayed when a battery is not inserted.
Setup Windows
Wireless Studio includes the following setup windows:
• [Property] window
• [Channel Plan Adviser] window
• [Omit IP address list] window
• [Setting lock] window
• [Receiver CH Label settings] window
• [GP/CH display setting] window
• [Display settings] window
• [Other settings] window
• [Network settings] window
• [Startup settings] window
• [Region setting] window
[Property] Window
This window allows you to view and change settings for
receivers and their paired transmitters.
a [Unlock Settings] / [Lock Settings] button
When setting modification is disabled due to the [Setting
lock] function, click this button and enter the password to
temporarily enable setting modification.
Close the [Property] window or click the button again to
relock settings.
1
2
3
4
