C:\Users\layinn\Desktop\FD\SY22_FD_UCM_RG_111\US\Map\FD\5037314111_US.fm master page: Left
XR-65A95K / 55A95K
5-037-314- 11 (1)
10 US
Detaching the Table-Top Stand from
the TV
To detach the Table-Top Stand from the TV,
remove the screws
.
Note
• Be careful when lifting the TV as the Table-Top
Stand is detached, the Table-Top Stand may
topple over and cause personal injury.
• Take care when removing the Table-Top Stand
from the TV to prevent it from falling over and
damaging the surface that the TV is sitting on.
• Do not remove the Table-Top Stand for any
reason other than to install corresponding
accessories on the TV.
• Be sure the TV is vertical before turning on. To
avoid uneven picture uniformity do not power
on the TV with the panel facing down.
• When attaching the Table-Top Stand again, be
sure to fasten the screws (previously removed)
to the original holes on the rear of the TV.
Installing the TV against a
wall or enclosed area
Ventilation
• Never cover the ventilation holes or insert
anything into the cabinet.
• Leave space around the TV set as shown
below.
Installed with stand
Installed on the wall
Never install the tv set as follows:
Note
• Inadequate ventilation can lead to overheating
of the TV and may cause damage to your TV or
cause a fire.
Using the Camera and
Microphone Unit (supplied)
A software update may be required to use
the Camera and Microphone Unit. For the
latest information about software updates
for your TV, visit:
https://www.sony.com/am/support
11
7
/
8
inches
4 inches
(30 cm)
(10 cm)
4 inches
(10 cm)
13
/
32
inches
(1 cm)
Leave at least this much space around the set.
11
7
/
8
inches
4 inches
Leave at least this much space around the set.
4 inches
4 inches
(30 cm) (10 cm)
(10 cm)
(10 cm)
13
/
32
inches
(1 cm)
Air circulation is blocked.
Wall Wall
Air circulation
Do not block the air circulation area.
