A. Group - Displays the selected group
B. Channel - Displays the selected channel
C. Frequency - Indicates the operating frequency of the selected Group and Channel.
D. Antenna Indicator - Indicates the active antenna (A or B).
E. Transmitter Battery Level - Indicates the battery level of the transmitter.
F. Audio Meter - Indicates the strength of the incoming audio signal.
G. RF Signal Meter - Indicates the strength of the incoming radio signal.
Receiver Display
A
D
F
G
E
B
C
