EXCELL PRECISION CO., LTD .
FM User Manual SME300000119 16
5-2 Internal Weight Calibration
Turn on and warm up the machine for 15 to 30 minutes before calibration.
Adjust calibration switch to “ON”, and the screen will display .
Press or to select .
Procedure
Zero
Calibration
Weight
Calibration
Zero Calibration
a ) Ensure nothing on the platter; after being stable, press , and the screen will display
“ ……. ”. The zero calibration will be complete 5 seconds later.
b ) To abort zero calibration, just press .
Weight Calibration
a ) Place an object, whose weight is known, on the platter, and input the weight value from
front panel. After being stable, press and the screen will display
“ ……. ”. The
weight calibration will be complete 5 seconds later.
b ) To abort weight calibration, just press .
Zero calibration complete
Confirmed
Calibration
Switch “OFF”
Place the
weight mass
and set the
weight
ENTER
ENTER ENTER
ENTER
E S C
ENTER
ENTER
E S C
TARE ZERO
E S C
E S C
