Sensoray 953-ET User Manual
Page 11
Audio/Video Input Connector: J1
Pin
Signal
Pin
Signal
1
Not Used *
2
PCIeGPIO4 *
3
PCIeGPIO3 *
4
PCIeGPIO2 *
5
PCIeGPIO1 *
6
Ground
7
Audio Input – Left, Channel 4
8
Audio Input – Right, Channel 4
9
Audio Input – Left, Channel 3
10
Audio Input – Right, Channel 3
11
Audio Input – Left, Channel 2
12
Audio Input – Right, Channel 2
13
Audio Input – Left, Channel 1
14
Audio Input – Right, Channel 1
15
Ground
16
Ground
17
Composite Video Input, channel 4
18
Ground
19
Composite Video Input, channel 3
20
Ground
21
Composite Video Input, channel 2
22
Ground
23
Composite Video Input, channel 1
24
Ground
Note:
*
Reserved for future use
V
Video Input Impedance: 75
Ω
A
Audio Input Impedance: 10
kΩ
Line inputs, designed to work with standard input level of 0.707V RMS
A/V (Video+Audio) Output Connector: J2
Pin
Signal
Pin
Signal
1
Audio Output – Left, Channel 4
2
Audio Output – Right, Channel 4
3
Audio Output – Left, Channel 3
4
Audio Output – Right, Channel 3
5
Audio Output – Left, Channel 2
6
Audio Output – Right, Channel 2
7
Audio Output – Left, Channel 1
8
Audio Output – Right, Channel 1
9
Composite Video Output, Channel 4
10
Ground
11
Composite Video Output, Channel 3
12
Ground
13
Composite Video Output, Channel 2
14
Ground
15
Composite Video Output, Channel 1
16
Ground
Note:
V
Video Output Impedance: 75
Ω
A
Audio Output Impedance: 10
kΩ
Line outputs, providing standard output level of 0.707V RMS
11
