NavCom SurveCE Integration Rev.A User Manual
Page 78
SurvCE™ Integration User Guide – Rev. A
3-76
In the current version of SurvCE, the
Message Type NCT will receive and
convert to the proper RTK types from the
base.
Note the version updates.
Wrenches icon
replaces Configure
button.
General layout of settings and labels.
4. Set the options if using the optional radio:
• Device: Internal UHF
• Base ID: If a Base ID is assigned to the base
station, enter the exact same network ID;
otherwise the rover will not receive
transmissions.
• Use Any Base ID: If desired, check this option
to permit the rover radio modem to receive
communications from any available base that
is transmitting on the same frequency.
5. Tap the
wrenches icon (Configure) button in
RTK view.
6. The Configure Satel/Internal UHF Radio window
opens (see Figure 41). Set the Channel frequency
for the rover radio modem as needed. Set the
Squelch to Medium or High to maintain the best
correction data integrity.
Do not change the RF power output, as
the rover is not transmitting.
