31) Timing/rpm sensor.
32) Oil temperature sensor (control unit).
33) 5.9 M E.C.U.
34) Neutral switch.
35) Oil pressure switch.
36) Front stop light switch.
37) Clutch switch.
38) Oil temperature sensor (instrument panel).
39) LH switch.
40) Air temperature/pressure sensor.
41) Instrument panel.
42) LH front turn indicator.
43) Headlight.
44) RH front turn indicator.
45) 24-pole release conn.
Wiring Colour Coding
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light Blue
Gr Grey
G Green
Bn Brown
O Orange
P Pink
Fuse box key (4)
Pos. El. item Val.
1-9 Main 30 A
2-10 Parking light, HIGH/LOW beam, 15 A
speed sensor and solenoid starter
3-11 ECU 3 A
4-12 Stop, horn, passing and key on 15 A
5-13 Instrument panel 3 A
6-14 Injection (injector, pump, coil) 20 A
Note
The system wiring diagram is at the end of this
manual.
