Toyotomi BS-35(F) - Manual (Page 17)

1
Kerosene-Fired Water Heater
Installation Manual
MODEL BS-35(F)
IMPORTANT
THIS APPLIANCE SHOULD BE INSTALLED BY A LICENSED, AUTHORIZED PERSON(S)
DUE TO THE NECESSITY OF MAKING ELECTRICAL, WATER AND FUEL CONNECTIONS.
RETAIN THIS MANUAL FOR FUTURE REFERENCE. CHECK LOCAL CODES AND
ORDINANCES FOR PERMITTED USE.
CAUTION
THIS WATER HEATER SHALL NOT BE USED FOR COMMERCIAL USE OR FOR ANY
PURPOSES OTHER THAN HOT WATER SUPPLY USES.OTHER USAGE MAY CAUSE A
MALFUNCTION OR SHORTEN ITS SERVICE LIFE. DO NOT REMOVE THE RATING PLATE
AND LABELS FROM THE WATER HEATER UNIT.
[CONTENTS]
SECTION A:
Fuel Pipe Installation..............…… 6
Safety Tips for Installation.............. 2
Removing Air Trap............……….. 7
Plumbing........……………………. 7
SECTION B: Electrical Wiring..............……… 9
Unpacking....................................... 3 Installation of Exhaust Pipe and
Standard Installation Parts.............. 3 Exhaust Pipe Top……………. 10
Dimensional Outline........................ 4 Check for Exhaust Pipe and
Exhaust Pipe Top…………… 12
SECTION C:
Installation SECTION D:
Selecting a Location........…......… 5 Test Run
Fuel Tank Installation...........…..... 6 Preparation................................... 13
Operation...................................... 13
