INSTALLATION
2
EXTERNAL TRIGGER/ENCODER
DS6300
A/B
Vext
B/A
V
+ 5V
~
~
+
-
Ground
Figure 26 - NPN Command Input Connection using External Power
EXTERNAL TRIGGER/ENCODER
DS6300
A/B
B/A
GND
V
+ 5V
~
~
+
-
Ground
VS
Figure 27 - NPN Command Input Connection using Scanner Power
EXTERNAL DEVICE
DS6300
IN3A
Vext
Ground
V
+ 5V
~
~
+
-
Ground
V
IN4A
+ 5V
~
~
+
-
INREF
Vext
Figure 28 - IN3/IN4 PNP Input Command using External Power
