Lingenfelter L650030504 Lingenfelter 2004 GTO Airbox Instructions v3.1 User Manual
Page 2
Page 1 of 9
Optional Items:
• LPE air filter service kit
SB-88-0005
• Replacement air filter
L660030504
Parts List
Quantity
Part Number
Description
1
LN-GTO-AB
airbox wall piece
1
LPE-01-WIRE-110
air intake hose
1
L660030504
air filter
1
50-350-188-110
straight black piece of silicon hose
1
EST-0653-26012
air temperature sensor grommet
1
AV15330
M6 X 1 flange nut
3
12335 A143
air box seals, 15 inches long each
1
53990110
large hose clamp
4
53980100
small hose clamp
1
23-923X
cable tie, black
4
KP82440
M5 X 0.8 X 16 mm stainless steel button head
4
47392
M5 stainless steel flat washers
8
47213
M5 stainless steel nylock nuts
1
XX09112-0001
airbox bracket #1
1
XX09112-0002-A
airbox bracket #2
1
XX09112-0004-B
airbox flange #2
1
XX09112-0005
tube assembly
1
1402
push-lock plastic river fastener
20”
1778
3/4” ID split loom, black (inches)
2”
1784
3/8” ID, 1/2” OD split loom, black (inches)
1
L920010000
LPE decal
1
Installation instructions
Recommended Tools:
• small flathead screwdriver
• fork type pry tool or equivalent
• T-30 Torx head screwdriver
• 3 mm Allen wrench
• ratchet
• 10 mm socket / wrench
• 8 mm socket / wrench
• WD40
