Parts List
# Part number Description
1 RPM-001 LPE Digital RPM Controlled Switch
1 hook & loop tape
2 AV16037 self-tapping screw
1 L920010000 LPE decal
1 instructions
Optional Items
• LED (for shift or indicator light)
• LED-RED-12-30 (12 volt, 30 cm wire red LED)
• LED-GREEN-12-30 (12 volt, 30 cm wire green LED)
• relay (for switching high current applications)
• MPH switch for triggering nitrous and other functions based on RPM & MPH
Specifications:
· The Lingenfelter Performance Engineering RPM-001 RPM Controlled Switch incorporates a preci-
sion 32-bit timer to realize microsecond precision over a very wide operating RPM range. Most
common tachometer pulse frequencies are supported with no special wiring or options required.
· RPM switch settings in 100 rpm increments from 500 to 19900 rpm for most common engine
applications.
· Fully encapsulated (potted) construction for increased durability.
· Rated for operation at up to 185 degrees F (85 degrees C).
· Outputs rated for up to 2.0 amps. For higher current levels, the switch should control a relay.
· Both the normally on and the normally off outputs can be used simultaneously.
· Can be used as an RPM activated switch or as a shift light controller. As a shift light controller, the
RPM-001 should be able to trigger most common 12 volt shift lights.
· Outputs have a self protect feature and will turn OFF in case of a direct short or over current condi-
tion.
· Operating voltage range: 9.0 to 16.0 volts.
· Input signal type: +12 volt square wave or coil negative terminal. Not for use with 5 volt reference
signals. For 5 volt reference signal applications (such as the GM coil signal, contact LPE for the low
voltage version of the RPM-001).
· Input signal impedance: 10k ohms.
· Current draw: 0.1 amp plus current draw of device being controlled (when active).
· 90 day warranty (from date of purchase).
