HITEC HFX-R User Manual

Hfx-r installation and set-up instructions

background image

Congratulations on your purchase of the HFX-R high frequency reversing electronic
speed control. The HFX-R represents the latest technology for high performance and
reliability in a reversing type ESC. Set it for two-way control for fun or forward only for
racing! The HFX-R does it all!

Step 1. Mounting instructions:

1.) Mounting the HFX-R should be done with double-sided tape in a location with

good airflow that does not interfere with the suspension of the vehicle.
Refer to your car instruction manual for their suggested location.

2.) On/Off switch should be mounted with double sided tape or screws where it is

easily accessible.

Step 2. Hook up Instructions:

1.) Connect the receiver lead to the throttle channel of the receiver.

This is typically CH#2. (Caution: The plug supplied will work with
Hitec, Futaba, JR and Airtronics "Z" only)

2.) Connect the ESC's Blue (-) and Yellow (+) wires to the motor via the

bullet connectors supplied.

3.) Connect the ESC's Tamiya type connector to the battery.

(Note: If you choose to use a different battery connector you will have to

change the stock connector to match.)

4.) Note: Always make sure you have three 0.1uf capacitors on the motor.

One from the positive motor tab to the ground (Case), the second from the
negative motor tab to the ground and the third from the positive motor tab to
the negative motor tab.

5.) Warning: Do not use a Schottky diode if using the reverse mode;

it may damage the speed control.

HFX-R

1

HFX-R Installation and Set-up Instructions

4

HFX-R

1. Technical Values

Operating Voltage Range : 6~7 Cells
BEC Output Voltage

: 5V

BEC Output Current

: 1A

Maximum Current

: 648A

Continuous Current

: 162A

Rated Current Brake / Rev : 80A
On Resistance Forward

: 0.004ohm

On Resistance Reverse

: 0.008ohm

Weight

: 56g(1.97oz)

Dimensions

: 41x34x28mm(1.6x1.3x1.1inch)

Temperature Overload

: 100~110c

PWM Frequency

: 1900hz

*Motor Limit

: 10 turn (Forward only)

when properly geared.

12 turn (Reverse)

2. Features

Microprocessor Controlled
Low Resistance
MOSFET Drive
Piezo Electric audio sound
Two Way or One Way

U.S. Service Procedure:

Send your defective product to:

Hitec Customer Service
12115 Paine St.
Poway, CA 92064

Include with your returned product:

- Your name, address and daytime telephone number.
- A detailed note stating exactly what went wrong and how happened.
- A copy of your original purchase receipt.
