4
User’s Manual
4
2.3.5. ABOUT
Displays screen with software versions,
website link, legal disclaimer and copyright
information. The Serial # information
displayed is a time/date stamp referenced to
GMT (Greenwich Mean Time) and has no
reference to the serial number sticker on the actual device.
2.4. Device Name
Assigns a descriptive name to the EMX-HD-AUD device that
is a maximum 8 characters long. The user is not allowed to
change the device name with multiple devices connected.
The FACTORY DEFAULT name is USBDEVHR.
2.5. Status Bar
The bottom bar of the screen shows the current USB status as follows:
“Scanning for Hardware…”
The GUI software is looking for EMX-HD-AUD devices.
Screen controls disable until a valid EMX-HD-AUD device
attached
“Connected – XX”
Where XX is the number of EMX-HD-AUD devices connected to the
PC.
2.6. CONTROL Group
VIDEO EDID
Clicking these controls selects to either PASS-THRU or
EMULATE the EDID.
PASS-THRU uses the SINK EDID while EMULATE uses the
internal EDID saved in the EMX-HD-AUD.
PASS-THRU is the FACTORY DEFAULT setting.
Learn EDID
Clicking this control will extract the EDID from device
connected to the output connector and save it in the unit.
The user must confirm the action.
