American Sanders RS-16DC Rotary Sander - Manual (Page 5)

EN ENGLISH
Clarke ® American Sanders Operator's Manual (EN) - RS-16 /RS-16DC - 5 -
Machine Specifications
Model RS-16 RS-16DC RS-16DC
Part Number 07161A 07162A 56381748
Voltage (Volts) 120 120 230
Frequency (Hz) 60 60 50
Current (Amps) 15 15 8.3
Pad /Brush Speed 175 rpm 175 rpm 145 rpm
Power 1.5 hp (1.1 kW) 1.5 hp (1.1 kW) 1.1 kW
Gearbox 3-Planet 3-Planet 3-Planet
Pad Driver Size 16” (41 cm) 16” (41 cm) 16” (41 cm)
Cord Length 50’ (15 m) 50’ (15 m) 50’ (15 m)
Height w/handle 46” (117 cm) 46” (117 cm) 46” (117 cm)
Weight w/cord 91 lbs. (41.1 kg) 91 lbs. (41.1 kg) 91 lbs. (41.1 kg)
Handle Tube Tubular Steel Tubular Steel Tubular Steel
Main Frame Die Cast Alum. Die Cast Alum. Die Cast Alum.
