Note: 1. Subject to change without notice.
2. Reference DOC-1242.
Specification, Dream Doc-1524 Rev. B Rev Date: 05/07/07
Dream Specifications Dimension One Spas
Shape Square
Seating Capacity 6
Shell Material Granitex™ / Acrylic
Dimensions 83" x 83" x 36" H / (211cm X 211cm x 91cm H)
Corner Radii 9" (23 cm)
Water Capacity 300 Gallons (1135 Liters)
Dry Weight 590 lbs (267 kg)
Shipping Weight 590 lbs (290 kg)
Full Weight 3090 lbs (1400 kg)
Skirt Material Synthetic
Poly Floor Yes
Water Treatment System n/a
Plumbing Systems 2
Filters/Coverage 1 / 75 sq. ft.
Gate Valves 0
VCR Jet® - Air Adjustable/Directional 1
VCR Jet® - Rotator 4
VCR Jet® - Dual Rotator 0
VCR Jet® - Multi Port Spinner 0
VCR Jet® - Mini Rotator 5
VCR Jet® - Mini Directional 2
VCR Jet® - Euro Directional 12
VCR Jet® - Euro Rotator 7
VCR Jet® - Mini Directional in NFJ 0
Typhoon Jet 0
Ozone Jet 1
Heater Return Jet 1
Pump Returns 4
Diverter Valves 0
Floor Drains n/a
Skimmer 8” Weir
Dynamic Massage Sequencer w/ control panel n/a
NeckFlex® Jet Pillows 0
Headrest Pillows X
Stereo system Optional*
Water Feature Yes
Water Feature Volume control Yes
Cup Holders 6
Tactile Therapy n/a
Pump Information Domestic (60Hz) Export (50Hz)
Motor Size – Peak (Continuous) HP 3.6 (2.0) HP 3.6 (2.0) HP
Jet Pumps # of Pumps/Speed One Dual & One single One Dual & One single
Circulation pump n/a n/a
Fountain pump n/a n/a
Electrical System Domestic (60Hz) Export (50Hz)
Voltage 240 240
Amperage 40/30 1X16 / 2X16 / 1X32
Heater 4.0 KW 2.0 KW
Thermostat Electronic Electronic
Light 1 with optional LED 1 with optional LED
Control System SSPA-1-D13 SSPA-1-D13-CE
Upper Control Programmable Digital Programmable Digital
Auxiliary Upper Control No No
Programmable Yes Yes
General
Water System
Special Features
