TECHNICAL SPECIFICATIONS
Model Number:
AC-10000E
Voltage / Frequency
115V/60H^
Power Consumption
909W / 8.3A
Air Volume (Maximum Speed)
300 m^/h
Dehumldificatlon Capacity
2.1 pints/hr(1 l_/hr)
Compressor Type
Rotary
Refrigerant Type
R-410A
Number of Fan Speeds
2
Timer
1 ~ 12 hours
Product Weight
50 lbs (23 kg)
Product Dimensions (W x D x
H)
12 3/16” X 13 13/16” X 27 15/16“
( 310 X 350 X 710 mm )
ADDITIONAL REMARKS:
Measuring conditions for the above specifications are as follows: DB = 95°F (35"C), WB= 82.94“F
(28.3'' C)
*DB = temperature of dry bulb = room temperature
*WB = temperature of wet bulb - relative humidity.
