ITEM
NO. PART NO. DESCRIPTION
QTY.
REQ'D
1 69004 Switch Actuator 1
2 69022 Upper Housing Assembly-Chrome 1
(Includes Upper housing and screws
(qty 3)
3 69024 Battery Assy. 1
(Includes battery and foam pad)
4 Lower Housing Assembly
(Includes lower housing, Neg and Pos
wires, Rivet (2), and housing screws
(3))
4a 69026 Lwr. Hsg. Assy. w/o pad print 1
5 69041 Motor Mount Assembly 1
(Includes motor mount, spring clip,
motor mount screws (qty 4) and motor
screws (qty 2))
6 69028 Motor Assembly 1
(Includes motor, cam, and black
rubber pads (qty 2))
7 29950 Switch 1
8 Adapter
8a 32770 Charger (BS) 1
8b 32775 Charger (CE) 1
ITEM
NO. PART NO. DESCRIPTION
QTY.
REQ'D
8c 32780 Charger (SAA) 1
IMPORTANT INFORMATION
When ordering repair parts, include part number, part name and model of trimmer. For best performance, trimmer blades should be CLEANED and OILED with Andis
Clipper Oil before and after use, If repair is necessary, return to any Andis Authorized Repair Service Station, or to Andis Company, 1800 Renaissance Blvd.,
Sturtevant, Wisconsin, 53177 U.S.A.. Pack carefully, mail either Insured Parcel Post, or U.P.S. , attach a letter to outside of package explaining difficulty.
Rev-A 4-24-06
