Section 8
Specifications
Specifications listed below are grouped by model number. Several attachments and kits are available which can improve the
performance and comfort of the unit. See page 9 for further details.
Dimensions: 13097,13099 ......... Eaton Hydrostatic Drive:
Length Model 751
All units... ................................................... 72” Speeds (in MPH)
Forward........0—6.3
Wheelbase Reverse........ 0—3.1
13095,13097............................................48.25”
13099... ................................................ 49.75”
Tire sizes
13096... ................................................ 51.5” 13095 Front...15x6.00-6RS
Rear ...20 x 8.00-8
Height
13095,13096........................................... 43” 13096,13097 Front...15x6.00-6RS
13097.... ................................................ 44.5” Rear ...20x8.00-10
13099... ................................................ 45”
13099 Front...16x 6.50-8
Width Rear ...23x10.50-12
13095,13096,13097................................. 35”
13099... ................................................ 38"
Lift
13095,13096,13097 ................ Manual w/spring assist
Engine................... .. .Briggs & Stratton: 13099.................... ................ Electric
13095............... ....Diamond Model 28M707-0615-A1
13HP Turning radius (inside rear wheel):
13096............... ....Vanguard Model 28P777-0635-A1 13095,13096,13097 ................................... 20”
13.5HP 13099......... .............................................. 22”
13097............... ....Vanguard Model 28Q707-0641-A1
15.5HP Ground clearance:
13037 .............. ....Vanguard Model 303777-0333-03 13095,13096,13097 .................................6.25”
16HP 13099......... ............................................8.25”
Transaxle Starter........................ ......................................... Electric
13095 .............. .....Peerless Gear Drive:
Model MST 205-5 Speed Attachment/PTO drive.... ......................................... Electric
Speeds (in MPH)
1st-1;2nd-2.2;3rd-3.3: Fuel capacity............... .......................................4 gallons
4th-4.2;5th-5.5;Rev.-1.9
Battery
13096 .............. ......Peerless Hydrostatic Drive: 13095,13096,13097........ 12V/190 ACC, 7-plate battery
Model VST 205 13099................ ............12V/295 ACC, 9-plate battery
Speeds (in MPH)
Forward........0—^5.5 Features;
Reverse........ 0—2.1 All units............. .................................... Headlights
All units............. ............. Attachment/PTO Drive Light
13096,13097,13099 ............................... Hour meter
13099 ............... ..Ammeter, Cruise Control, Electric Lift
35
