Components Wetted parts
Inlet stainless steel*
Outlet
Pump
Pump + AK + EK
stainless steel**
PBT
Hoses PTFE, antistatic
Fittings ETFE / stainless steel*
Housing cover insert PTFE, carbon reinforced
Head cover ETFE, carbon reinforced
O-ring in head cover FPM
Diaphragm clamping disc ETFE, carbon reinforced
Valve FFKM or PTFE
Diaphragm PTFE
Overpressure safety relief device
stainless steel***, PTFE, carbon reinforced,
FFKM
Separator cover plate PTFE, carbon reinforced
Catchpot, collecting flask,
vapour condenser
borsilicate glass
* stainless steel 1.4404
** stainless steel 1.4541
*** stainless steel 1.4404 and 1.4310
Position Component
12 exhaust waste vapour condenser
13
coolant inlet
(hose nozzle 6 mm)
14
coolant outlet
(hose nozzle 6 mm)
15 catchpot
16 cover plate
17 collecting flask
18 immission condenser
Position Component
1 inlet (vacuum connection)
2 outlet (gas!)
3 on/off switch (0: off, 1: on)
4 rating plate
5 handle
6
gas ballast connection
(only inert gas)
7 inlet inert gas purge
8 outlet inert gas purge
9 overpressure valve
10 antistatic connection
11 mains cable
Wetted parts
Pump parts
