Craftsman 316.2927 User Manual
Page 15
15
Sears Craftsman 4 Stroke Cultivator / Edger Model 316.29270
Ref.
No.
Part No.
Part Description
1.
747-1320
Throttle Control
2.
732-1038
Torsion Spring
3.
725-2009
On/Off Switch
4.
720-0294
Foam Grip
5.
746-1147
Throttle Cable
6.
749-1294A
Upper Handle
7.
731-1268
Upper Handle Connector
8.
710-0405
Carriage Screw 5/16-18 x 3.0
9.
725-0157
Cable Tie
10.
718-0812
Drive Shaft
11.
731-1267
Lower Handle Connector
12.
720-0241
Wing Nut 5/16-18
13.
736-0451
Shoulder Washer .320 ID x .93 OD
14.
749-1295
Lower Handle
15.
710-0395
Hex Cap Screw 5/16-18 x 2.25
16.
749-1299
Front Handle
17.
712-3004A
Flange Lock Nut 5/16-18
18.
714-0104
Cotter Pin
19.
686-0181
Tailpiece Bracket Assembly
20.
711-1017
Clevis Pin
21.
710-3013
Hex Cap Screw 1/4-20 x .50
22.
712-3027
Hex Lock Nut 1/4-20
23.
726-0299
Cap Push
24.
686-0182
Wheel Support Bracket Assembly
25.
734-1988
Wheel 7.0
26.
710-3015
Hex Cap Screw 1/4-20 x 1.75
27.
736-3020
Flat Washer .271 ID x .630 OD
28.
786-04000
Tine Shield
29.
686-0194
Gearbox
31.
686-0179
Inner Tine
32.
686-0178
Outer Tine
33.
686-0177
Inner Tine
34.
686-0176
Outer Tine
35.
714-0220
Click Pin
36.
686-0183
Edger Tine
37.
734-2026
Edger Wheel 5.0
Ref.
No.
Part No.
Part Description
