Load under test host pc – Maxim Integrated 78M6613 Evaluation Board User Manual
Page 10
78M6613 Evaluation Board User Manual
UM_6613_045
10
Rev. 2
78M6613 Eval Board
78M6613
Isolation
Current
Shunt
UART
USB
USB
Controller
5x DIOs I2C
3V3 Reg
5V
Load Under Test
Host PC
120/240V
Single Phase
AC Source
Voltage
Divider
Optos
Neutral
Line
J3
J4
J6
J8
Earth Gnd
Figure 2: 78M6613 Evaluation Board Application Diagram
