HOOK ASSEMBLY FOR METAL FRAME POOLS
English
HOOK ASSEMBLY
1
2
3 4
Connect the skimmer
hose (16) to the
skimmer (10)
bottom connector.
Assemble the hook as shown.
Loosen the skimmer
screw (11), attach the
assembled hook and hand
tighten the screw.
NOTE: Do not over
tighten or use tools
such as pliers.
Place the whole assembled
hook unit over the top of a
frame pool horizontal beam near the
water inlet connector (lower hose
connection). Adjust the hook by
adjusting the two dove-tail screws, to
be tight on
the top beam.
Ensure the
hook is
securely
tightened
over the
pool top
beam.
10
16
Press Press
Insert
Insert
12
15
Slide
11 Top Beam
