8
ADDR ：001-H
BAUD RATE ：9600
PARITY ：None
SOFTWARE ：V1.00.0.R
INITIALIZATION COMPLETED
SYSTEM INFORMATION
DISPLAY SETTING
CAMERA SETTING
FUNCTION SETTING
ALARM SETTING
EXIT
Note:
z
ERR means current setup is invalid.
z Please make sure all the cable connections are right.
3.2 Self-diagnosis System Information
After installation, please connect speed dome to power. The system goes on a self-diagnosis, and then it
pops up the above interface to show the system information.
If there is anything wrong during the self-diagnosis, system pops up error code.
The above interface disappears after speed dome received the first command (or the display time lasts for 4
minutes.)
z
ADDR: Here you can view dome address information. For example, 001-H, 1 is the address number, -H
is hard address mode. –S is software address mode.
z Baud rate: Dome communication baud rate.
z Parity: Communication parity bit format.
z Software: Dome software version of the control firmware.
When you are using the control keyboard or the matrix host to control the device via the RS485 BUS,
please make sure the control parameter of the keyboard or the matrix host is the same with the
speed dome OSD (including address, baud rate, parity). The protocol can be one of the protocols the
speed dome supported. Please make sure the cable connection is OK.
3.3 Main Menu
You can open the IP dome menu via monitor platform, Web, control keyboard, matrix, or speed dome
control terminal.
z SYSTEM INFORMATION：Dome self-diagnosis information, address information, system time setup,
set north direction, language, factory default setup, reboot and so on.
z DISPLAY INFORMATION: Display dome preset title, azimuth display, time, direction, zoom, dome internal
temperature and etc information.
z CAMERA PARAMETERS ：Set camera white balance setup, camera exposure setup, day/night setup,
focus setup, picture adjust, zoom speed, aperture setup, aperture control level, digital zoom, flip, freeze,
output mode, stabilization, factory default, reboot and etc.
z FUNCTION SETTING: Set preset, pan, scan, auto cruise, pattern, idle motion, time task and privacy mask
function.
z ALARM SETTING: Set alarm number, action, activation mode, serial number, relay output, reset delay
